If one B-spline surface was a set of Bézier- or B-spline surfaces then
the same problems which we had with curves do occur. Fairing without changing
the method, the resulting patches are smooth but not the whole surface. Two
possible solutions are given for this problem: remove as much as possible knots
(see [5]) or use an extended functional.
One proposal for this new functional is
which is also a mixture of energy and continuity minimization.
As for curves, the solution of minimizing this functional can be splitted into
an energy and continuity one, which should not be given here. |
